Centrifuge Footprint
The US Filtermaxx leg-type centrifuge mounts on a standard 55-gallon drum or comparable stand, minimizing floor space in the installation area.
| Specification | Value |
|---|---|
| Machine weight (model dependent) | 106 – 126 lbs |
| Base footprint | Fits standard 55-gallon drum lid (~22.5" diameter) |
| Height above drum | ~30 inches |
| Typical overall height with drum stand | 48 – 54 inches |
Recommended Clearances
| Direction | Minimum Clearance | Purpose |
|---|---|---|
| Front | 24 inches | Bowl removal, valve and dial access |
| Sides | 18 inches | Hose routing, belt inspection |
| Rear | 12 inches | Motor cooling airflow, wiring access |
| Top | 24 inches | Lid opening, spindle removal |
| Floor | Level, solid, firm surface | Vibration dampening and stability |
Multi-Unit Installations
For high-volume operations, US Filtermaxx centrifuges are commonly installed in banks of 4–6 units in parallel.
Multi-Unit Guidelines
- Allow 18" minimum between adjacent units (side clearance × 2)
- Plan shared manifold feed and collection piping to reduce overall footprint
- A single US Filtermaxx automatic controller can sequence multiple centrifuges
- Contact US Filtermaxx for site-specific multi-unit layout recommendations
Note: Refer to the dimensional drawings available from US Filtermaxx for exact clearance specifications and installation diagrams.
