2400G DC Centrifuge | Benchtop Mount | Commercial Grade [US-Filtermaxx]

⚠ Configurations over 150 lbs (for example with the power lead kit or vibration isolators added) ship LTL freight — shipping is not calculated at checkout; please submit a quote request for a freight estimate.

Run your centrifuge on battery power — no AC outlet required.

The US Filtermaxx 2,400G 12V DC centrifuge delivers the same proven separation performance as the AC model, powered entirely by 12V DC. Perfect for mobile lube service trucks, marine vessels, off-grid solar systems, RVs, farm equipment and any installation where AC power is unavailable.

Specifications:

• G-force: 2,400G
• Bowl capacity: 1 gallon displacement (165 cubic inches sludge capacity)
• Throughput: 360–1,000 gallons per day depending on fluid and contamination level
• Feed rate: 10–40 GPH
• Input: 1/4 inch NPT
• Output: 1-1/4 inch NPT
• Spindle: 1 inch diameter with replaceable bearings (load carried by spindle, not motor bearings)
• Body: 1 inch thick aluminum for rigidity and minimal vibration
• Rotor: Machined aircraft-grade aluminum casting
• Bowl removal: Quick-release spindle — under 1 minute
• Machine weight: 120 lbs nominal
• Assembly: some assembly required — approx. 30–60 minutes
• Footprint: Fits on top of a 55-gallon drum
• Power: 12V DC
• Motor: 1/2 HP industrial DC, NEMA 56C frame, reversible

Key features:

• Submicron particulate removal
• Forced ventilation — exhausts vapors from waste oil and biodiesel processing, prevents water vapor contamination of clean oil, vents methanol vapors
• Internal dam separates clean and dirty oil
• Belt overdrive system — rotor spins at high speed while motor runs at 1,800 RPM for quieter, cooler, longer-lasting operation
• Optional automatic controllers (Basic or Deluxe) — cycle and drain sludge for unattended operation up to 1,000 gallons per day

Designed, made and tested in USA.

Typical applications:

• Mobile lube service and oil change rigs
• Marine vessel fuel and oil processing
• Off-grid solar and battery-powered installations
• Farm and remote site fuel polishing
• WVO, WMO, biodiesel, diesel, hydraulic oil

⚠ Never introduce liquid into an empty bowl at full speed. Fill the bowl during start-up acceleration to prevent bowl imbalance.

Centrifugal separation effectiveness depends on the particle class being separated:

• 100–1,500G — Macro/Cellular: whole cells, sand, large debris
• 1,500–10,000G — Microbial/Organelle: bacteria, fine emulsions, oil contamination
• 10,000–30,000G — Subcellular: mitochondria, DNA precipitates

Higher G-force provides better separation quality for finer particles — not necessarily higher flow rate.

Ships without power leads — select the 30 ft DC Power Lead Kit option (1/0 AWG, Anderson SB175, 90 A) when ordering, or wire the motor directly to your DC power source.

Vibration isolator option — select it when ordering to add 4 isolator feet (CST-313), or add them later.

Special PTFE seals are available if needed for your application — request a quote or call 601.651.0007.

DC models (12V / 24V): ship without power leads or plug — wire the motor directly to your DC power source.
