High Speed Cylinder Centrifuge | Industrial Grade [US-Filtermaxx] — 5HP / 15,700G / 316 GPH / 1,200 LPH

⚠ Ships LTL Freight. Shipping is not calculated at checkout — please submit a quote request for a freight estimate before ordering.

Industrial high-speed cylinder centrifuge for continuous three-phase separation at 316 GPH. Built for clarifying liquids, separating difficult emulsions of two liquids with light concentrations of suspended solids and a small differential in specific gravity.

At 15,700G and 16,300 RPM with a 2.1 gallon (8 liter) 304 stainless steel bowl, this machine delivers precise liquid-liquid-solid separation across a wide range of fluid types. Two interchangeable components give the operator full control over the separation zone:

• 3 interchangeable separating rings of different diameters control the separation boundary between the two liquid phases in the top of the cylinder
• 4 interchangeable feed nozzles in the bottom of the centrifuge body control input flow rate

Specifications:

• Bowl speed: 16,300 RPM
• G-force: 15,700G
• Bowl capacity: 2.1 gallons (8 liters)
• Throughput: 316 GPH (1,200 L/hr)
• Motor: 5 HP (3 kW), 3-phase
• Power: 230V — 1-phase or 3-phase
• Construction: 304 stainless steel throughout
• Drive: Variable speed, soft start
• Dimensions: 36"L × 24"W × 63"H
• Shipping weight: 1,100 lbs — ships via motor freight

Key features:

• 15,700G at 16,300 RPM — higher RPM than the 400 GPH model for challenging fine separations
• Three-phase separation — two liquid phases plus solids simultaneously
• Adjustable separation rings — precisely control the liquid-liquid boundary for each fluid
• Interchangeable feed nozzles — dial in exact flow rate for your viscosity and clarity target
• Variable speed with soft start — gentle ramp-up protects the bowl and extends bearing life
• 5HP motor — higher torque for demanding industrial applications
• 304SS construction — food-grade, chemical-resistant, easy to clean
• 1-phase or 3-phase available — same unit, choose your power configuration

Typical applications:

• Tramp oil separation and oil purification
• Coconut oil, avocado oil, and vegetable oil separation and degumming
• Hemp oil and botanical extract clarification
• Biodiesel production — water washing and glycerin separation
• Oil-water separation — emulsions with tight specific gravity differentials
• Protein extraction and concentration
• Plant and herb extraction
• Dewatering — yeast, bacteria, and biological solids
• Molasses refining
• Milk and cream separation

Choosing between the 316 GPH and 400 GPH models:

Both centrifuges are built for the same three-phase separation applications, but they trade throughput for rotational performance in opposite directions:

• 316 GPH (this model) — 5HP, 16,300 RPM, 15,700G — higher rotational speed means greater centrifugal force per unit of bowl radius, better suited for very fine particle separations, tight specific gravity differentials, and viscous fluids that need more residence time at high G to release their solids
• 400 GPH model — 4HP, 15,000 RPM, 15,860G — higher throughput for the same G-force range; the right choice when volume is the priority and the separation is not at the extreme end of difficulty

If your process sits at the edge of what a centrifuge can separate — very similar fluid densities, very fine solids, or highly emulsified streams — the 316 GPH model's higher RPM gives you more headroom. If you need to move more volume and your separation is moderately challenging, the 400 GPH model is the better value.
