High Speed Cylinder Centrifuge | Industrial Grade [US-Filtermaxx] — 5HP / 15,860G / 400 GPH / 1,515 LPH

⚠ Ships LTL Freight. Shipping is not calculated at checkout — please submit a quote request for a freight estimate before ordering.

Industrial high-speed cylinder centrifuge for continuous three-phase separation at 400 GPH. Purpose-built for clarifying liquids, separating difficult emulsions of two liquids with light concentrations of suspended solids and a small differential in specific gravity — the exact scenario where standard centrifuges struggle and the cylinder centrifuge excels.

At 15,860G and 15,000 RPM with a 2.2 gallon (8 liter) stainless steel bowl, this machine handles the full spectrum of liquid-liquid-solid separation challenges. Two interchangeable components let the operator precisely tune the separation zone for each application:

• 3 interchangeable separating rings of different diameters control the separation boundary between the two liquid phases in the top of the cylinder
• 4 interchangeable feed nozzles in the bottom of the centrifuge body control input flow rate

This level of adjustability makes the 400 GPH cylinder centrifuge equally capable across a wide range of fluid types and separation targets — from light vegetable oils to heavy tramp oil, from delicate protein streams to dense bacterial suspensions.

Specifications:

• Bowl speed: 15,000 RPM
• G-force: 15,860G
• Bowl capacity: 2.2 gallons (8 liters)
• Throughput: 400 GPH (1,515 L/hr)
• Motor: 5 HP (3 kW) (3 kW)
• Power: 230V — 1-phase or 3-phase
• Construction: 304 stainless steel throughout
• Drive: Variable speed, soft start
• Dimensions: 36"L × 24"W × 63"H
• Shipping weight: 1,166 lbs — ships via motor freight

Key features:

• 15,860G — extreme centrifugal force for difficult separations with small specific gravity differentials
• Three-phase separation — separates two liquid phases plus solids simultaneously
• Adjustable separation rings — precisely control the liquid-liquid boundary for each fluid
• Interchangeable feed nozzles — dial in the exact flow rate for your viscosity and target clarity
• Variable speed with soft start — gentle ramp-up protects the bowl and extends bearing life
• 304SS construction — food-grade, chemical-resistant, easy to clean
• 1-phase or 3-phase available — same unit, choose your power configuration

Typical applications:

• Tramp oil separation and oil purification
• Coconut oil, avocado oil, and vegetable oil separation and degumming
• Hemp oil and botanical extract clarification
• Biodiesel production — water washing and glycerin separation
• Oil-water separation — emulsions with tight specific gravity differentials
• Protein extraction and concentration
• Plant and herb extraction
• Dewatering — yeast, bacteria, and biological solids
• Molasses refining
• Milk and cream separation
